European Type Electric Hoist
European Type electric hoist adopts the European FRM design standard with advance concepts ,beautiful shape.The drive unit adopts domestic advanced ponts line meshing gear structure making the machine has compact resaonable structure.The operation is simple ,convenient and working is safety and efficient and meet the low noice ,energy conservation and environmental protection requirements.
Performance Description :
-
Customized service: customized to meet the needs of various customers at home and abroad
-
World class standard: SEW, ABM three-in-one operation, Schneider Electric
-
Long service life: working level up to A6, light weight, low height and low failure
Features :
1. Overload protection
The core component of the lifting mechanism - the electronic pressure sensor, imported from Germany. Accurate and reliable electronic overload protection can effectively prevent overload during operation and enhance the safety of the equipment. The overload protection device cooperates effectively with the control circuit to prevent further increase of the load in the event of an overload and to ensure that the load can be safely lowered.
2.Lifting reducer
-
Aluminum shell, light weight ,Anti-corrosion
-
Stable operation
-
Anti-corrosion ,free maitance
3.Lifting Brake :
Two-disc electric disk brake with up to 1 million brakes and no maintenance during safe use
-
Maintenance free, self-regulating
-
Dust-proof design for long service lif
-
Fast action and high reliability
4.Drum,wire rope ,rope guide
The reel is made of high-quality seamless steel pipe by CNC machine tool. The rope groove on the
reel can becombined with the rope guide to prevent loose rope and chaotic rope.
The steel wire rope adopts high-strength imported steel wire rope with tensile strength of 2160N/mm2,
which has good safety performance and long service life.
5.Traveling Mechanism
We provide two schemes for different working condition : G-Series and F-Series ,"Three in one " traveling driven ,adpots Germany ABM .
1. How to get offer ?
These requirements are required :
1). Lifting capacity
2). Lifting height
3). Power supply
4). Quantity
2. Payment Terms : T/T,L/C ......
3. Delivery Time : Nornamlly Within 10-20 days after receiving your payment
4. Package : International standard package --- Sea worthy wooden box
5. Warranty : 18months
